Beschrijving
- Programmable trough readers
- 4000 users (Cards)
- 2 reader inputs (Auto detect Wiegand26 / Wiegand34)
- 2 door relays (2 x 250VAC/4A)
- 2 door sensor inputs 2 push button inputs
- 2 Alarm relays: Output 1 (door forced alarm), Output 2 (door left open alarm)
- Programming done with Master1&2,
- Delete, Reset APB, Master 1 and Master 2 card
- Adjustable Door relay time (1 – 250sec, or ON/OFF(toggle) mode)
- Anti Pass Back option
- Normal wiegand mode (card only) and LCSP mode (card and PIN code) on any reader
- Shadow delete card – per user or per group of users
- Max. Users in 1 groups: 4000 (each group has 1 card)
- Single door mode / 2 readers (one reader on each side of the door)
- 2 door mode / 2 readers (one reader on each door)
- 60 sec lockout after 15 invalid cards
- Enroll sequential block of cards – max. block of 100 cards
